GPS Tracker FMB920
Small and smart GPS tracker with 2G connectivity
The FMB920 is a small and smart tracker with Bluetooth connectivity, internal High Gain GNSS and GSM antennas and an integrated backup battery. Compact, reliable, accurate and enduring — all of its interfaces are more than enough for basic tracking. The Digital Input can be used for ignition, door or alarm button status monitoring, while remote vehicle immobilising is achieved through the Digital Output. The Analog Input extends usage scenarios with temperature, humidity and liquid level monitoring. A perfect choice for basic track & trace and fleet management across any fleet or transportation type.
- Power Supply
- 6 – 30 V DC
- Connectivity
- GSM / GPRS + Bluetooth® 4.0 LE
- Positioning
- GPS, GLONASS, Galileo, BeiDou
Key features
- Extensive monitoring — remote engine blocking among numerous fleet control measures
- Crash detection based on accelerometer data
- Eco-driving / Green Driving scenario for all-round better driving
- Bluetooth® LE for beacons, sensors, headsets and OBDII dongles
- Over speeding, jamming, excessive idling, unplug and towing detection
- Auto and manual geofencing with trip reporting
- GNSS fuel counter and LLS / OBDII fuel monitoring
- FOTA Web firmware updates and remote configuration via SMS or GPRS
Applications
- Track & trace for mixed fleets
- Fuel and eco-driving monitoring
- Geofencing and trip reporting
- Remote engine immobilising
Technical specifications
| Module | Teltonika TM2500 — GSM/GPRS/GNSS/Bluetooth® LE |
|---|---|
| GNSS | GPS, GLONASS, GALILEO, BEIDOU, SBAS, QZSS, DGPS, AGPS |
| Receiver | 33 channel, tracking sensitivity −165 dBm |
| Position Accuracy | < 2.5 CEP, velocity < 0.1 m/s |
| Start Times | Hot < 1 s, warm < 25 s, cold < 35 s |
| Cellular | GSM quad-band 850 / 900 / 1800 / 1900 MHz, GPRS Class 12 |
| Power Supply | 6 – 30 V DC with overvoltage protection |
| Backup Battery | 170 mAh Li-Ion (0.63 Wh) |
| Bluetooth® | 4.0 + LE, beacons, sensors, OBDII dongle |
| Interface | 1 digital input, 1 digital output, 1 analog input, Micro-USB 2.0 |
| Memory / SIM | 128 MB internal flash, Micro-SIM |
| Dimensions | 79 × 43 × 12 mm, 54 g |
| Operating Temperature | −40 °C to +85 °C, IP54 |
| Certification | CE/RED, E-Mark, EAC, Anatel, ICASA, NTC, REACH, RoHS |
Specifications may be tailored for OEM/ODM and private-label programs.
